VI-6762 Addressable Fire Repeater
VI-6762 Addressable Fire Repeater
Key Features
*Full info display from a remote location
* Installed at reception or supervised position of each floor
* Full message displayed same as the fire alarm panel
* Mini and attractive structure design
* Equipped(Equipped) with 4.3 inches touch screen for graphic display
* Occupy one address, able to view message from cross-loop
* USB port available for easy updating
* Multi languages ensure a user-friendly system
* 24VDC power supply required, but low power consumption
Description
SPECIFICATION
* Power Supply: DC24V
* Operating Voltage: DC15V–28V
* Alarm Current: ≤60mA
* Standby Current: ≤0.7mA
* Standby Power: ≤1W
* Display: 100 alarmed address
* Temperature: 0°C to 45°C
* Relative Humidity: ≤95%RH at 40°C, non-condensing
* Address: 0#–255#
* Installation: Wall-mount
* Dimension: 171×140×32mm
